EndoRotor® Set-up
EndoRotor® System Powered Endoscopic Debridement Quick Start Guide for Necrosectomy
This technique guide is intended as a physician supplement to the EndoRotor System Instructions for Use (IFU). Please consult the IFU for complete details, precautions, and troubleshooting.
a. Ensure Catheter Interface on console is in unlock position xx.
b. Insert catheter’s proximal housing into connection. Ensure hex connection aligns. Gently push catheter’s housing completely inward and rotate locking lever right into locked position.xx
c. On bottom surface of proximal housing are 2 connected tubing sets. The shorter of the 2 is the purge kit connection vacuum tube. To load press vacuum release button xx Stretch tube and place in to vacuum release valve until seated.
d. Place the purge kit saddle into the accessory holder and confirm it is seated. Connect the vacuum tubing directly to smaller end of the purge kit until firmly seated. The bottom section of the purge kit must be connected to vacuum tubing. Remaining tubing will be connected to an overflow canister which will be connected to the portable Medela vacuum.
e. Use vented spike on irrigation tubing to attach to saline bag. Open irrigation pump by lifting the irrigation pump hood. Place the irrigation tubing set on top of rollers with flow from left to right. Close irrigation pump hood.
f. Press prime button. xxOnce primed, amber light turns green, and system is ready for use.
EndoRotor® System Endoscopic Powered Resection Quick Start Guide for Mucosectomy
This technique guide is intended as a physician supplement to the EndoRotor System Instructions for Use (IFU). Please consult the IFU for complete details, precautions, and troubleshooting.
a. Ensure Catheter Interface on console is in unlock position. xx.
b. Insert catheter’s proximal housing into connection. Ensure hex connection aligns. Gently push catheter’s housing completely inward and rotate locking lever right into locked position.xx
c. On bottom surface of proximal housing are 2 connected tubing sets. The shorter of the 2 is the specimen trap connection vacuum tube. To load press vacuum release button xx Stretch tube and place in to vacuum release valve until seated.
d. Connect vacuum tubing directly to top section of the specimen trap with a press fit until firmly seated. The bottom section of specimen trap must be connected to vacuum tubing. Remaining tubing will be connected to an overflow canister which will be connected to the portable Medela vacuum.
e. Use vented spike on irrigation tubing to attach to saline bag. Open irrigation pump by lifting the irrigation pump hood. Place the irrigation tubing set on top of rollers with flow from left to right. Close irrigation pump hood.
f. Press prime button. xxOnce primed, amber light turns green, and system is ready for use.
